Features:
• 130L high-flow for rapid coaling
• Maximum pressure 3Bar, efficient working point 51L@23M
• Intelligent frequency conversion control
• Extreme low temperature cold starting at -40°C, stable flow
• 20,000 hours long lifetime
| Model | Max Flow (L/Min) |
Max Head (M) |
Rated Voltage (VDC) |
Rated Current (A) |
Rated Power (W) |
| TA90E-A48-13030 | 130 | 32 | 48 | 7.5 | 350 |
OEM Customization Available
Technical data
| Motor Type | Brushless DC Motor |
| Ambient Temperature | -40～55℃ |
| Liquid Temperature | -40~80℃ |
| Media | Water, Coolant |
| Working Voltage | 48V |
| Ideal Life Time | >20000 Hours |
| IP Level | IP67 |
| OD(inlet / outlet) | 20mm / 20mm OEM Customization Available |
| Working Mode | Continuous |
| Power Supply | DC power supply, battery powered |
| Remarks | Can't dry-running, not self-priming |
TA90E High Pressure Liquid Cooling Pump Applications: EV charger liquid-cooling system, Chiller, Energy storage cooling, Industrial & Commercial electronics cooling, Thermal management system, Medical cooling, Server Data Center cooling / CDU cooling
EV Charger
Server Cooling
Chiller
Medical Cooling
Function:
PWM, FG (RPM) signal wire
Strength:
♦ 16000㎡ modern factory with its own physical property rights, ESD anti-static control dust free workshop,100+ sets of professional imported equipment
♦ 4 major professional and precision laboratories that meet the CNAS national laboratory accreditation standards
♦ More than 60 patents in the micro dc pump industry, strong research and development strength, and master advanced industry technology
Max Flow：42L/MIN
Max Head：30M
Max Flow：35L/MIN
Max Head：21M
